BHP-0301
品牌:Musta
Detail



FEATURES:

1.One HDMI input signal split to two/four/eight/sixteen HDMI sink devices

2.Support 3D

3.Support CEC

4.Support deep color 30bit, 36bit

5.Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC

6.Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

7.Support signal retiming

8.Support input up to 15metres AWG26 HDMI standard cable length,

   output up to 25metres AWG26 cable length

9.No loss of quality

10.Installs in minutes

11.Need DC5V/1A power supply



SPECIFICATIONS:

HDMI resolution

24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i

Support video color format

24bit/deep color 30bit,36bit

Support audio format

DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

Max bandwidth

225MHz

Max baudrate

6.75Gbps

Input/Output TMDS signal

0.5~1.5Volts p-p(TTL)

Input/Output DDC signal

5Volts p-p (TTL)

Input cable distance

≤15m AWG26 HDMI standard cable

Output cable distance

≤25m AWG26 HDMI standard cable

Max working current

500mA

Power adapter format Input

AC (50HZ, 60HZ) :100V-240V; Output: DC5V/1A

Operating Temperature range

(-15 to +55°C)

Operating Humidity range

5 to 90%RH (No Condensation)

Dimension (L x W x H)

105X50X20mm

Weight

130g/150g/180g/200g
